Sapphire PULSE AMD Radeon RX 7600 OC 8GB
- Spesifikasjoner
- Produktinfo
-
Generelt Garanti (måneder) 18 Tilstand Brukt Status Testet Produktnummer 11324-01-20G / S88-2E452-020SA Produkttype Grafikkort Busstype PCI Express 4.0 x8 Grafikkprogram AMD Radeon RX 7600 Kjerneklokke 1876 MHz Boost Clock 2755 MHz CUDA-kjerner / Strømningsprosessorer 2048 Maks. oppløsning 7680 x 4320 Maks. antall skjermer som støttes Prosessteknologi Grensesnitt 1x HDMI 2.1a
3x DisplayPort 2.1Støttede API Egenskaper UEFI BIOS, Game Driver Optimizations, RDNA 3 Gaming Architecture, Bakplate i aluminium, AMD Radeon Anti Lag Technology, Sapphire Dual-X Cooling Technology, AMD FidelityFX Super Resolution 2 (FSR), Precision Fan Control, 2-slot Fan Cooler, Sikringsvern, TriXX Boost, Radeon Image Sharpening, 32 regneenheter, AMD Smart Access Memory-teknologi, Intelligent Fan Control (IFC), Dual Fan Design, Komposittvarmerør, Dual ball Bearing Fans, TriXX Supported, AMD Radeon Boost Technology, AMD VR Ready Premium, AMD Infinity Cache, FreeSync Technology, 32 Ray Accelerators, Video Streaming inntil 8 K, AMD Radeon Super Resolution (RSR) EAN 4895106293618 Minne Størrelse 8 GB Teknologi GDDR6 SDRAM Minnehastighet 18 Gbps Bussbredde 128-bit Båndbredde Systemkrav Strømkontakter 8-pins PCI Express-strømkontakt Anbefalt strømforsyning 550 W Diverse Tilpassede standarder Høyde 10.71 cm Bredde 24 cm Dybde 4.407 cm Farge Svart / Rød -
Sapphire PULSE AMD Radeon RX 7000 Series
Digital Power Design
SAPPHIRE NITRO+ & PULSE AMD Radeon™ RX 7700 Series are designed with digital power which provides accurate power control and excellent power efficiency
Ultra High Performance Conductive Polymer Aluminum Capacitor
The Ultra High Performance Conductive Polymer Aluminum Capacitor has a small PCB foot print but high volumetric capacitance that makes 14-phase power possible on the RX 7700 series graphics card. The capacitor offers stable capacitance at a high frequency and temperature with very low signal noise, ensuring the stability and reliability of the product.High TG Copper PCB
The GPU is mounted on to the high-density 14 layer 2oz Copper and high TG PCB to match the rapid speed, high current and increased power requirement of the GPU and memory to guarantee high stability of the PCB during operation.
Angular Velocity Fan Blade
The Angular Velocity Fan Blade provides a double layer of downward air pressure which alongside the air pressure on the outer ring of the Axial fan, results in up to 44% more downward air pressure and up to 19% more airflow for a quieter and cooler operation when compared to the previous generations.
Optimized Composite Heatpipe
The composite heatpipes are fine-tuned for each individual cooling design with optimal heat flow, efficiently and evenly spreading out the heat to the entire cooling module.
Fuse Protection
In order to protect your card, the SAPPHIRE cards have fuse protection built into the circuit of the external PCI-E power connector to keep the components safe.
Two-Ball Bearing
These feature Dual Ball bearing fans, which have an approximately 85% longer lifespan than sleeve bearings in our tests. The improvements to the fan blades means the solution is up to 10% quieter than the previous generation.
