ASUS Z170-DELUXE - LGA1151-1
- Spesifikasjoner
- Produktinfo
-
Generelt Garanti (måneder) 18 Tilstand Brukt Status Testet Produktnummer Z170-DELUXE Produkttype Hovedkort Brikkesett type Prosessorsokkel LGA1151-1 Kompatible prosessorer EAN 4712900113884 Støttet RAM Maks størrelse 64GB Teknologi DDR4 SDRAM Bussklokke 4 x DIMM DDR4 3733(O.C.), 3600(O.C.), 3466(O.C.), 3400(O.C.), 3333(O.C.), 3300(O.C.), 3200(O.C.), 3000 (O.C.), 2800(O.C.), 2666(O.C.), 2400(O.C.), 2133(O.C.) MHz Støttet RAM-integritetskontroll Ikke-ECC Registrert eller bufret Ikke-bufret Egenskaper Grafikk Maks allokert RAM-størrelse Lyd Type Audio Codec Realtek ALC1150 Tilpassede standarder LAN Nettverkskontroller Intel I219V Gigabit LAN controller
Intel I211-AT Gigabit LAN controllerNettverksgrensesnitt GigabitEthernet
Wi-Fi 802.11a/b/g/n/ac
Supports dual-band frequency 2.4/5 GHz
Supports ASUS Wi-Fi Go Utility
Up to 1300 Mb/s transfer speed
Bluetooth v4.0
Ekspansjon / Tilkoplinger Utvidelsesspor Lagergrensesnitt Intel Z170 chipset
1 x SATA Express port, compatible with 2 x SATA 6 Gb/s ports
1 x M.2 x4 Socket 3, with M key, type 2242/2260/2280/22110 storage devices supported (both SATA & PCIE mode)
6 x SATA 6 Gb/s ports, gray
Supports Raid 0, 1, 5, 10
Intel Rapid Storage Technology supported
Support Intel Smart Response Technology
ASMedia SATA 6 Gb/s controller
2 x SATA 6 Gb/s ports, blackRAID-funksjoner Grensesnitt 1 x DisplayPort
1 x HDMI
2 x LAN (RJ-45)
5 x USB 3.1 (teal blue) type-A
1 x USB 3.1 type-C
1 x USB 3.0 (blue)
1 x USB 2.0 (port can be switched to USB BIOS Flashback)
1 x Optical S/PDIF out
1 x ASUS Wi-Fi GO! module (Wi-Fi 802.11 a/b/g/n/ac and Bluetooth v4.0/3.0+HS)
6 x Audio jacksInterne overflater 1 x AAFP connector
2 x USB 3.0 connectors support additional 4 x USB 3.0 ports
2 x USB 2.0 connectors support additional 4 x USB 2.0 ports
1 x SATA Express connector
1 x M.2 Socket 3 with M Key design, type 2242/2260/2280/22110 storage devices support (Supports both SATA & PCIE SSD)
1 x TPM header
6 x SATA 6 Gb/s connectors
1 x CPU fan connector (1 x 4-pin)
1 x CPU OPT fan connector (1 x 4-pin)
4 x Chassis fan connectors (4 x 4-pin)
1 x Thunderbolt header
1 x 24-pin EATX power connector
1 x 8-pin ATX 12 V power connector
1 x EZ XMP switch
1 x System panel (Q-Connector)
1 x 5-pin EXT_FAN (Extension Fan) connector
1 x DRCT header
1 x MemOK button
1 x Thermal sensor connector
1 x TPU switch
1 x EPU switch
1 x Power-on button
1 x Reset button
1 x Clear CMOS button
1 x USB BIOS Flashback button
1 x 14-1 pin TPM connectorStrømkontakter Egenskaper BIOS Type BIOS-egenskaper Sov/Våkne Maskinvarefunksjoner Diverse Høyde 30.5 cm Bredde 24.4 cm -
